Laser Tube Cutter Machine Video:
Tube Laser Cutter Features:
1).The laser tube cutter can be used for round tube, square tube, rectangular tube, oval tube and other kinds of pipes;
2).High performance IPG or Raycus fiber laser with stable performance, service life is more than 100,000 hours;
3).professional chuck clamping system for tube laser cutting machine, pipes of different shapes & sizes can be precisely cut;
4).High quality transmission mechanism and servo motor from top rated suppliers to guarantee the high running accuracy;
5).High-efficiency detection of pipe profiles to realize the deviation of all-meter cutting precision within 0.15mm;
6).short waster tailings and co-edge cutting function reduce the subsidiaries and save production costs;
Techinical Parameters:
Item | Specification |
Name | Entry Level CNC Fiber Tube Laser Cutter Machine For Sale |
Model | JSF-6016E |
Pipe Length | 6000mm |
Diameter Range | Φ20x20mm -Φ160x160mm; |
Profile Type | Round, square, rectangular, oval, etc |
Laser Power | 1000W/1500W/2000W/3000W |
Cutting Thickness | Upon actual fiber laser source |
Rated Output Power | 10–100% (100W-1000W) |
Positioning Accuracy | ±0.03mm |
Re-positioning Accuracy | ±0.02mm |
Max.Loading Capacity | 600KG |
Power Supply | 3-phase, 380V, 50Hz/60Hz |
fiber tube laser cutter Projects:
Steel Tube Laser Cutting Machine Application:
Applicable Profiles:
Tube laser cutter machine can be used for cutting & intersecting of various tubes such as round pipe, square tube, rectangular tube, U-shaped tube, elliptical tube, angle steel, channel steel, H beam, etc., the machine is suitable for different metal materials, including carbon steel, stainless steel, alloy steel, aluminum, copper, titanium, etc.
Applicable Industries:
Laser tube cutter machine can be widely used in sports equipment, kitchen equipment, bathroom equipment, small hardware processing, auto parts processing, petroleum pipeline, furniture, props, clothing props display stand, medical equipment, steel furniture, door and window kitchen, steel furniture industry, etc.
Packaging & Delivery:









FAQs About Fiber Tube Laser Cutter Machine:
Q: Is the structure strong one or light duty type?
A: The machine body is reliable strong one which is welded by steel tube & plates, some are even casted ones, quite suitable for industrial purposes. Also, the mounting base surface for linear guides and racks is all precisely milled via a metalworking 5-axis CNC machining center.
Q: What is the cutting thickness?
A: The cutting thickness depends on actual power & material to be cut, 2 options of fiber laser sources are available: IPG and Raycus, and we will recommend some best model as soon as your thickness and material detail is well confirmed.
Q: Is there any consumable for the machine?
A: Consumables are quite necessary for fiber laser cutter, you can buy some consumables from us or buy from your local market, we can provide the consumable list.
Q: Is further installation required for oversea customers?
A: The machine is complicated equipment and further installation & commissioning are required. Our after-sales service team will be sent there for the service & support, you can also send your staff here to our factory for training on installation & operation;
