Laser Cutter Metal Machine Video:
Hobby Metal Laser Cutter Features:
1).This laser metal cutter machine has durable machine structure welded by steel plates and well processed by machining centers, stable structure to guarantee high cutting accuracy and excellent cutting performance;
2).Open worktable, simple operation and small space occupation;
3).China top Cypcut CNC control system for metal laser cutter machine, advanced function & easy to learn, more flexible and efficient processing;
4).Advanced nesting software automatically adjusts focusing lens to realize automatic perforating and cutting plates of different thickness;
5).German IPG and China Raycus/Maxphotonics fiber laser ranging from 500-2000w, good beam quality, big cutting capacity and maintenance free essentially, working time can be 100,000 hours;
6).Swiss Raytools laser cutting head with automatic focusing & follow functions;
7).Japan Yaskawa/Panasonic Servo Motors, big torque and high sensitivity;
8).Japan/Taiwan transmission system & guide rails guarantee the high precision & stable running performance;
Techinical Parameters:
| Item | Specification | ||
| Name | Best Hobby Metal Laser Cutter Machine For Sale | ||
| Model | JSF-3015S | JSF-4015S | JSF-4020S |
| Working Area | 3000*1500mm | 4000*1500mm | 4000*2000mm |
| Machine Structure | Single open table structure | ||
| Laser Type | Fiber laser generator | ||
| Laser Power | 1000W/1500W/2000W/3000W/4000W, etc. | ||
| Graphic Format Supported | CAD, DXF, etc. | ||
| Positioning Accuracy | ±0.01mm | ||
| Re-positioning Accuracy | ±0.01mm | ||
| Max. Speed | 80-120m/min. | ||
| Power Supply | 3-phase, 380V, 50Hz/60Hz | ||
Laser Cutter Metal Projects:
Best Hobby Laser Cutter Application:
Applicable Materials:
Best laser cutter for metal is suitable for stainless steel, carbon steel, silicon steel, aluminum alloy, titanium alloy, galvanized steel, pickle plate, aluminum-plating zinc plate, metallic copper and other metals.
Applicable Industries:
Laser metal cutter for sale is widely used in kitchen appliances, sheet metal cabinet, Machinery equipment, Hardware lighting, doors & windows manufacturing, advertising label, auto parts, decoration, air ship, medical apparatus and instruments, mining equipment, metal working industry, etc.
Packaging & Delivery:
FAQs About Fiber Laer Cutting Machine:
Q: Is the structure strong one or light duty type?
A: Machine body of the hobby metal laser cutter is reliable strong one which is welded by steel tube & plates, some are even casted ones, quite suitable for industrial purposes. Also, the mounting base surface for linear guides and racks is all precisely milled via a metalworking 5-axis CNC machining center.
Q: What is the cutting thickness?
A: The cutting thickness depends on actual power & material to be cut, 2 options of fiber laser sources are available: IPG and Raycus, and we will recommend some best model as soon as your thickness and material detail is well confirmed.
Q: Is there any consumable for the machine?
A: Consumables are quite necessary for fiber laser cutter, you can buy some consumables from us or buy from your local market, we can provide the consumable list.
Q: Is further installation required for oversea customers?
A: The machine will be packaged after removing some auxiliary device, it will be ready for work as soon as the wire & cable are connected, the further installation will be quite simple, some instruction document will be sent along with the machine. equipment and further installation & commissioning are required. Our after-sales service team will be sent there for the service & support, you can also send your staff here to our factory for training on installation & operation;
